JBL

JBL STUDIO 650P

Details
Variations

Home Audio Loudspeaker System

For Bulk Enquiry: Click Here

High definition imaging for high fidelity sound.

For those searching for a home audio speaker system that goes above and beyond what they’ve ever heard, seek no further: The new JBL Studio 6 speaker system is everything your inner audiophile could hope for. Enjoy the top-ranked sound of its PolyPlas cones; marvel at the concert-grade accuracy and power of its acoustics speaker drivers; and get electrified by its HD imaging waveguide, complete with high-frequency compression driver. It features a modern new clean look that’s equally stylish and easy to set up. After JBL Studio 6, home listening will never sound – or feel – the same.

Item# JBLS650PWAS

General Specifications

10" Powered sub-woofer system with 500W amplifier Yes
10" (254mm) PolyPlas Low-Frequency Woofer Yes
Power 250W RMS (500W Dynamic)
Frequency Response 28 Hz - 150 Hz
Crossover Frequencies 50Hz – 150Hz (variable) 24dB/octave
Controls Auto Power, Crossover, Level, Phase
Input One (1) Line-Level LFE Input
Enclosure Type Bass-Reflex via Bottom-Firing Tuned Port
Power Requirement 120V, 60Hz (US) ; 220V-230V, 50/60Hz (EU)
Power Consumption (Idle/Full/Power) <0.5W (standby)/335W/2.1A (max – 230V)/335W/4A (max – 120V)
Dimensions (W x D x H) 395 x 395 x 395mm
Click here for a complete list of all specs for this product

Spec Sheet (English)

English 638 KB
  • 1 x JBL Studio 650P – 500 Watts Powered Subwoofer
  • 1 x Power Cord
  • 1 x Owner’s Manual
  • 1 x Warranty Card
  • 1 x Safety Sheet
  • 4 x Carpet Spikes
